Laser Beam

LASER BEAM 300 IP

FEATURES

Laser Beam 300 IP is an exceptional new designing iluminaire of next generation. It pushes all the limits when it comes to beam definition, with native contrast never before achieved by a laser light source. It also adopts Carbon fiber and Aeronautical materials as its body appearance, and particularly style of waterproof rated IP66 with high temperature resistance of up to 180°C and corrosion. Continuous rotation of infinite Pan movement. Laser Beam 300 IP well developed to enable the fixture remaining easily accessible and limited in weight of 20kg. Making this luminaire a universal tool capable of meeting any challenge in all conditions.

SPECIFICATION

POWER SUPPLY

Voltage: AC100-240V 50 / 60Hz

LIGHT SOURCE

Light source: 300W white laser light source

Consumed power: 400W

Light source life: 30,000 hours

Luminous flux: 12000lm

Light source color temperature: 7000K

CRI: greater then 64

Laser illumination: 430000 lux/20 meters

OPTIC

Beam angle: 0.72 degree

Aperture of exit lens: φ 168mm

EFFECT

Color: 1 color wheel, 14 colors + white, bi-direction rotating rainbow effect

Gobo: 1 fixed gobo wheel, 19 gobos + white, can share in both directions

Prism: 8 prism, honeycomb prism, multiple prism macro combination effects

Soft light effect: adjustable independent soft light effect

Focusing: electric focusing

Strobe: 1-25 times/second adjustable pulse flicker and random flicker

Dimming: 0-100% linear adjustment

MOVEMENT

Movement: Pan infinite movement, 16 Bit fine adjustmemt

Titl 270 degrees, 16 Bit fine adjustmemt

Pan/Tilt scanning speed: standard and adjustable speed

Pan/Tilt scanning system: Pan/Tilt can automatically correct and calibrate

CONTROL

Channel mode: standard 16CH

Control: DMX 512 RDM bidirection data transmission, console can remotely reset

DMX address code

Intelligent control: menu can record device usage time and fixture time, display

device temperature, channel data and software version information.

BODY

Display: 1.7-inch LCD display screen with touch button

Carbon fiber and Aeronautical materials

Seetronic Powercon True1 & XRL

Protection level: IP66

Carton dimensions: 60*54*46cm

Net weight: 20Kg
