LIGHT SOURCE & OPTIC
Light source: Ushio 450W(Optional Philips 420W LL)
CRI up to 77
Lifespan: 3500H
Color temperature: 7800K
Lens diameter: 180mm
Beam angle: 1.7 degrees
EFFECT
Fixed color wheel with 12 dichroic colors
CMY color mixing system
3600-6600K CTO linear adjustable
1 Static Gobo Wheel with 17 gobos
1 Linear heavy frost 15° for wash effect
Total 6 kinds of prism with rotation in both directions at variable
speed to make 15 kinds of Prism effect
Strobe: Multiple speed strobe
Dimming: 0-100% smooth dimming
Focus: Electric focus system
CONTROL & PROGRAM
4 touch buttons
Control: DMX512/RDM optional Artnet/CRMX
DMX Channel: 21CH
POWER SUPPLY
Input voltage: AC100-240V 50/60Hz
Consumed Power: 600W
Power connectors: Seetronic PowerCon True1 IN/OUT
DMX connectors: Seetronic 3-Pin XLR IN/OUT Optional 5Pin
MOVEMENT
Pan: 540 degrees / Tilt: 270 degrees
P/T position: Auto correction
P/T: 16bit scanning
BODY
Working in any position
Magnesium Aluminum IP66 body
Pan/Tilt lock for safe transportation and maintenance
Two side hidden handles for transportation
